Custom Forged Flange Manufacturer in China
Specialized in forging, HDC promises to forge the best suitable flange for your piping system. You design it, we make it come true.
Forgeage à haute résistance
Solution personnalisée tout-en-un
Certifié ISO et IATF
Types of Forged Flange
HDC manufactures most types of flanges on the market, and a customized model is also available.
Bride à enfiler
The slip-on flange is suitable for low to medium pressure pipe systems. You can easily slip it onto the pipe and weld it together. At HDC, we use CNC machining to precisely control tolerances and sealing surface finish, ensuring a perfect match and reducing leakage risk after welding.
Bride à collerette soudée
The weld neck flange has a tapered hub to butt weld with the pipe. This shape can transfer stress from the flange to the pipeline, forming a high-strength linkage, so it’s mainly used in high-pressure applications. By forging, we can produce it with high strength and low flaws to ensure safety.
Socket Weld Flange
You can plug the pipe into the socket of a socket flange, then install it by fillet welding. It’s preferred for small-bore and high-pressure piping systems. HDC combines forging and CNC finishing to ensure both the strength and precise geometry of the socket, making it a reliable component for your project.
Bride filetée
This type of flange has an internal thread and can be installed on a pipe with a matched external thread without welding. This means it’s suitable for low-pressure pipelines that need frequent disassembly and maintenance. With the multi-axis CNC machine, we can perform high-precision thread turning to ensure perfect engagement.
Blind Flange
Unlike other flanges, the blind flange is basically a solid disc without a central hole. It is used for sealing off a pipe, valve, or pressure container. Therefore, it needs to withstand high pressure. That’s why we use forging to fabricate the blind flange for an even, flawless, and dense grain structure to ensure rigidity under full load.
Lap Joint Flange
A lap joint flange comes with two parts: a flange and a stub end. During installation, the stub end is assembled with the flange and then inserted into the pipe. Then the stub end is welded to the pipe, leaving the flange free to rotate for convenient alignment of the bolt hole. We manufacture it with CNC to ensure smooth, unobstructed rotation.
Pourquoi choisir HDC
What sets HDC apart from the hundreds of forging factories in China? Here is the answer.
Forgeage à haute résistance
Equipped with dozens of forging presses and screw presses, HDC is able to perform cold and hot close die forging to produce flanges with high strength and quality.
Usinage CNC de précision
We forge and CNC finish flanges in-house with our comprehensive CNC machines, including 3, 4, and 5-axis CNC machining centers, with which we can achieve a tolerance of ±0.05mm.
Certified Materials
With over 20 grades of metal provided, HDC forged flanges that are best suited for your project. All our materials are purchased from reputable manufacturers and can offer certifications upon request.
One-Stop Forging Solution
HDC can provide a one-stop customization service from mold manufacturer to CNC finishing to build your flanges from scratch, backed by our comprehensive in-house manufacturer capabilities.
How HDC Fabricates Forged Flange
Learn how HDC fabricates custom-made flanges for industries around the world.
Forgeage
First, we forge the flange blank into a near-net shape using close-die forging, which is very close to the final product and requires minimal post-machining.
Traitement thermique
After forging, we introduce heat treatment processes according to the material, performance requirements, and applications to enhance the strength of a flange.
Finition CNC
In this step, we perform CNC turning, milling, and drilling using our multi-axis CNC center to finish the critical dimensions of a flange like the mounting surface, positioning hole, etc
Consultez notre contrôle de qualité méthodes de forgeage de pièces.
Matériaux disponibles
All your material needs for a flange can be satisfied in HDC.
Carbon steel is a cost-effective material for flanges because it can be easily formed by forging and has a lower material price. Flanges made by it are primarily used in a pipe system that does not transfer corrosive media, such as water, air, oil, etc.
HDC offers a wide range of carbon steel for forging flanges, including Q355B, Q235, 20#, et 45#.
Alloy steel is a common material for flanges used in high-temperature steam, chemical process pipelines, and boilers. They have added certain elements to enhance properties, such as Chromium, Molybdenum, and Nickel, resulting in better strength and corrosion & heat resistance than carbon steel.
HDC forges flanges with a wide range of alloy steel, including 20Cr, 20CrMo, 40Cr, and 42CrMo.
Due to stainless steel’s excellent corrosion resistance and antibacterial properties, flanges made of it are favored in piping systems for industries such as chemicals, food processing, pharmaceuticals, seawater processing, and highly corrosive liquids.
Stainless steel is easy to form by forging. This is also what HDC specializes in; we can forge 304, 316L, 316Ti, et 2205 for your customized flange.
Super alloy flange can maintain high strength, corrosion resistance, and creep resistance under extreme conditions, and is an essential component in gas turbines, high-temperature heat exchangers, nuclear reactors, petrochemical, and marine engineering.
At HDC, you can get Inconel, Monel, et Stellite for custom flanges designed for harsh environments.
Available Surface Treatments
HDC forges and finishes the flange with comprehensive in-house capabilities.
This is an important surface treatment for flanges made of stainless steel, as it can form a thick oxide layer on a flange’s surface to enhance its corrosion resistance. This step is done in-house with our automated pickling equipment.
Polishing is often applied to flanges after forging or CNC machining to remove scale and tool marks. It can also improve the surface finish by bringing a mirror or stain finish for flanges made of stainless steel or super alloy. This treatment can also be done by our mechanical polishing and vibratory polishing.
Cooperating with reliable surface treatment factories, HDC can provide comprehensive coatings for your customization project, including epoxy coating, zinc coating, etc.
Spécifications techniques
Veuillez vous familiariser avec nos capacités de production avant de demander un devis.
| Forging Capacity | 160T – 4000T pressing force |
| Échelle de poids | 0.01 kg – 30 kg per piece |
| Size Range | DN15 – DN1200 (1/2″ – 48″) |
| Machining Tolerance | ±0.05 mm (after machining) |
| Finition de surface | Ra 0.8 – 12.5 μm (as required) |
| Traitement thermique | Normalizing, quenching, tempering, annealing, stress relieving |
| Contrôle de qualité | Analyse de la composition chimique des matériaux Mechanical property testing Contrôle dimensionnel (CMM) Hardness testing Penetrant testing Ultrasonic testing (on request) |
| Facing Types | Flat face (FF), raised face (RF), ring type joint (RTJ) |
| Certificat | Material certificates, dimensional reports per request |
| Capacité de production | 50,000+ pieces per month |
| Délai de mise en œuvre | 30-60 days (depending on quantity and complexity) |
Need Custom Flanges for Your Piping System?
Contactez HDC et bénéficiez de la solution complète et experte en matière de produits de forgeage. Envoyez-nous simplement un e-mail, notre devis est gratuit !
FAQ
What is a flange used for?
A flange is a mechanical connector that joins pipes, valves, pumps, or other equipment together. It allows easy assembly and disassembly of piping systems, while ensuring a tight seal to prevent leaks.
What are the different types of flange?
There are several common types of flanges, including Slip-On, Weld Neck, Socket Weld, Threaded, Blind, and Lap Joint. Each type has its own structure and application, from low-pressure pipelines to high-pressure, high-strength systems.
What is the most commonly used flange?
Slip-On and Weld Neck flanges are the most popular. Slip-On flanges are easy to install, while Weld Neck flanges are preferred for high-pressure applications because they transfer stress to the pipe for a stronger connection.
How to choose flange type?
It depends on your application. Consider the pipeline pressure, size, installation method, and whether you need to frequently disassemble the system. Slip-On is great for low to medium pressure, Weld Neck for high pressure, Blind for sealing, and Threaded for maintenance-friendly setups.
What are forged flanges?
Forged flanges are made by shaping metal under high pressure, creating a dense, strong grain structure. Compared to plate flanges, they have higher strength, better toughness, and lower risk of flaws. They are ideal for high-pressure or critical applications.
What is the difference between plate flange and forged flange?
Plate flanges are cut and machined from flat metal plates, while forged flanges are shaped under high pressure from solid metal. Forged flanges are stronger, more reliable under stress, and less prone to cracks or defects.
Does HDC provide prototypes for forged flanges?
Yes! HDC can produce prototypes before mass production, so you can check fit, dimensions, and quality before committing to a full order.
